Hanbell Medium to High Temperature Unit
Ang Hanbell medium to high temperature screw unit ay isang high-efficiency, integrated refrigeration solution na partikular na idinisenyo para sa medium hanggang high evaporating temperature applications. Binibigyang-diin ng unit ang katatagan ng system, pagiging maaasahan ng pagpapatakbo, at kadalian ng paggamit sa mga proyekto sa engineering. Nagtatampok ito ng compact, all-in-one na istraktura na lubos na nagsasama ng screw compressor, oil separator, oil cooler, liquid receiver, economizer, pressure controller, at electrical control cabinet. Bukod pa rito, nilagyan ito ng modular frame, shut-off valve, check valve, safety valve, at oil injection system, na naghahatid ng fully functional na refrigeration unit mula mismo sa pabrika. Pinapasimple ng pinagsamang disenyo na ito ang on-site na pag-install at pag-commissioning, pagpapabuti ng kahusayan ng proyekto.
Ang unit ay komprehensibong na-configure, kasama ang lahat ng pangunahing bahagi ng pagpapalamig at mga elemento ng kontrol na nagmula sa mga kilalang tatak upang matiyak ang coordinated na operasyon sa pagitan ng mga bahagi, pagpapahusay sa pangkalahatang pagiging maaasahan ng system at kaligtasan ng pagpapatakbo. Ang disenyo ng modular frame ay nagbibigay ng flexibility para sa pagpapalawak o pagpapanatili sa hinaharap, na binabawasan ang pangkalahatang pagiging kumplikado ng pagpapatakbo at pagpapanatili habang tinitiyak ang pare-parehong pagganap sa ilalim ng katamtaman hanggang mataas na mga kondisyon ng temperatura.
Panimula sa Mga Parameter ng Kagamitan
Pagpapakita ng Detalye
Makipag-ugnayan sa Amin
Panimula sa Mga Parameter ng Kagamitan
| Modelo ng Unit | Com.Model | Com, Cuartity | Pagkondensasyon temp. (℃) | Pagsingaw Temp. (℃) | Reservoir (L) | Supply tubo (mm) | Pagsipsip tubo (mm) | Gas Outiet tubo (mm) | likido inlettubo (mm) | Dimensyon(mm) (LxW×H) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Coling Capacity/Power Input (kw) | |||||||||||||||||||
| LXPL-BHF-30M | RC2-100B -Z (30HP) | 1 | 35 | 47. | 18.7 | 38.1 | 19.4 | 70.6 | 20.1 | 85.2 | 20.7 | 101.2 | 21.2 | 80 | Φ28 | Φ54 | Φ42 | Φ35 | 1700×900×1100 |
| 40 | 43.8 | 20.4 | 34.1 | 21.2 | 66.4 | 22.0 | 80.3 | 22.7 | 96.4 | 23.3 | |||||||||
| 45 | 40.3 | 22.2 | 50.0 | 23.1 | 61.6 | 24.0 | 74.8 | 24.8 | 90.4 | 25.3 | |||||||||
| LXPL-BHF2 -60M | RC2-100B -ZP (30HP) | 2 | 35 | 94.2 | 37.4 | 116.2 | 38.8 | 141.2 | 40.2 | 170.4 | 41.4 | 202.4 | 42.4 | 100 | Φ35 | Φ89 | Φ54 | Φ35 | 2300×1700×1800 |
| 40 | 87.6 | 40.8 | 108.2 | 42.4 | 132.8 | 44.0 | 160.6 | 45.4 | 192.8 | 46.6 | |||||||||
| 45 | 80.6 | 44.4 | 100.0 | 46.2 | 123.2 | 48.0 | 149.6 | 49.6 | 180.8 | 50.6 | |||||||||
| LXPL-BHF3 -90M | 3 | 35 | 141.3 | 56.1 | 174.3 | 58.2 | 211.8 | 60.3 | 255.6 | 62.1 | 306.3 | 63.6 | 150 | Φ42 | Φ89×2 | Φ54 | Φ42 | 3000×1700×1800 | |
| 40 | 131.4 | 61.2 | 162.3 | 63.6 | 1992 | 66.0 | 240.9 | 68.1 | 289.2 | 69.9 | |||||||||
| 45 | 120.9 | 66.6 | 150.0 | 69.3 | 184.8 | 72.0 | 224.4 | 74.4 | 271.2 | 75.9 | |||||||||
| LXPL-BHF4 -120M | 4 | 35 | 188.4 | 74.8 | 232.4 | 77.6 | 282.4 | 80.4 | 340.8 | 82.8 | 408.4 | 84.8 | 200 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 3700×1700×1800 | |
| 40 | 1752 | 81.6 | 216.4 | 84.8 | 265.6 | 88.0 | 321.2 | 90.8 | 385.6 | 93.2 | |||||||||
| 45 | 161.2 | 88.8 | 200.0 | 92.4 | 246.4 | 96.0 | 299.2 | 99.2 | 361.6 | 101.2 | |||||||||
| LXPL-HF -40M | RC2-140B -Z (40HP) | 1 | 35 | 65.1 | 24.4 | 80.2 | 25.4 | 97.6 | 26.3 | 117.8 | 271.0 | 141.0 | 27.8 | 80 | Φ28 | Φ54 | Φ42 | Φ35 | 1730×700×1100 |
| 40 | 60.7 | 26.6 | 74.9 | 27.7 | 91.7 | 28.7 | 110.9 | 29.6 | 133.2 | 30.4 | |||||||||
| 45 | 55.9 | 29.1 | 69.3 | 30.3 | 85.2 | 31.4 | 103.4 | 32.5 | 124.9 | 33.4 | |||||||||
| LXPL-BHF2 -80M | RC2-140B -ZP (40HP) | 2 | 35 | 130.2 | 48.8 | 160.4 | 50.8 | 1952 | 52.6 | 235.6 | 54.2 | 282.0 | 55.6 | 150 | Φ35 | Φ108 | Φ54 | Φ35 | 2300×1700×1800 |
| 40 | 121.4 | 53.2 | 149.8 | 55.4 | 183.4 | 57.4 | 221.8 | 59.2 | 266.4 | 60.8 | |||||||||
| 45 | 111.8 | 58.2 | 138.6 | 60.6 | 170.4 | 62.8 | 206.8 | 65.0 | 249.8 | 66.8 | |||||||||
| LXPL-BHF3 -120M | 3 | 35 | 195.3 | 73.2 | 240.6 | 76.2 | 292.8 | 78.9 | 353.4 | 81.3 | 423.0 | 83.4 | 200 | Φ42 | Φ89×2 | Φ76 | Φ42 | 3000×1700×1800 | |
| 40 | 182.1 | 79.8 | 224.7 | 83.1 | 275.1 | 86.1 | 332.7 | 88.8 | 399.6 | 91.2 | |||||||||
| 45 | 167.7 | 87.3 | 207.9 | 90.9 | 2556 | 94.2 | 310.2 | 97.5 | 374.7 | 100.2 | |||||||||
| LXPL-BHF4 -160M | 4 | 35 | 260.4 | 97.6 | 320.8 | 101.5 | 309.4 | 105.2 | 471.2 | 108.4 | 564.0 | 111.2 | 250 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 3800×1700×1800 | |
| 40 | 242.8 | 106.4 | 299.6 | 110.8 | 366.8 | 114.8 | 443.6 | 118.4 | 532.8 | 121.6 | |||||||||
| 45 | 223.6 | 116.4 | 277.2 | 121.2 | 340.8 | 125.6 | 413.6 | 130.0 | 499.6 | 133.6 | |||||||||
| LXPL-HF -50M | RC2-180B -Z (50HP) | 1 | 35 | 85.9 | 30.3 | 105.3 | 31.5 | 128.1 | 32.6 | 154.6 | 33.6 | 185.1 | 34.5 | 100 | Φ35 | Φ67 | Φ42 | Φ35 | 2300×900×1100 |
| 40 | 79.8 | 33.1 | 98.4 | 34.4 | 120.4 | 35.7 | 145.6 | 36.8 | 174.8 | 37.8 | |||||||||
| 45 | 73.6 | 36.1 | 91.1 | 37.6 | 112.3 | 39.0 | 136.2 | 40.3 | 163.9 | 41.5 | |||||||||
| LXPL-BHF2 -100M | RC2-180B -ZP (50HP) | 2 | 35 | 171.8 | 60.6 | 210.6 | 63.0 | 2562 | 652 | 309.2 | 67.2 | 370.2 | 69.0 | 200 | Φ42 | Φ108 | Φ76 | Φ42 | 2300×1700×1800 |
| 40 | 159.6 | 66.2 | 195.8 | 88.8 | 240.8 | 74.1 | 291.2 | 73.6 | 349.6 | 75.6 | |||||||||
| 45 | 147.2 | 72.2 | 182.2 | 75.2 | 224.6 | 78.0 | 272.4 | 80.6 | 327.8 | 83.0 | |||||||||
| LXPL-BHF3 -150M | 3 | 35 | 257.7 | 90.9 | 315.9 | 94.5 | 384.3 | 97.8 | 463.8 | 100.8 | 555.3 | 103.5 | 250 | Φ54 | Φ89×2 | Φ76 | Φ54 | 3500×1700×1800 | |
| 40 | 239.4 | 99.3 | 295.2 | 103.2 | 361.2 | 107.1 | 436.8 | 110.4 | 524.4 | 113.4 | |||||||||
| 45 | 220.8 | 108.3 | 273.3 | 112.8 | 336.9 | 117.0 | 408.6 | 120.9 | 491.7 | 124.5 | |||||||||
| LXPL-BHF4 -200M | 4 | 35 | 343.5 | 121.2 | 421.2 | 126.0 | 512.4 | 130.4 | 618.4 | 134.4 | 740.4 | 138.0 | 300 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 4400×1700×1800 | |
| 40 | 319.2 | 132.4 | 393.8 | 137.6 | 481.6 | 142.8 | 582.4 | 147.2 | 699.2 | 151.2 | |||||||||
| 45 | 294.4 | 144.4 | 364.4 | 150.4 | 449.2 | 156.0 | 544.8 | 161.2 | 655.6 | 166.0 | |||||||||
| Modelo ng Unit | Com.Model | Com. Curtity | Pagkondensasyon temp. (℃) | Evaporation Temp.(℃) | Reservoir (L) | Supply tubo (mm) | Pagsipsip tubo (mm) | Gas Outiet tubo (mm) | likido inlettubo (mm) | Dimensyon(mm) (L×W×H) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasidad ng Paglamig/Pewer Input(kw) | |||||||||||||||||||
| LXPL-BHF-55M | RC2-200B -Z (55HP) | 1 | 35 | 91.9 | 33.6 | 113.1 | 34.9 | 137.6 | 36.1 | 166.1 | 37.3 | 198.9 | 38.2 | 100 | Φ42 | Φ76 | Φ42 | Φ54 | 2300×900×1100 |
| 40 | 85.7 | 36.6 | 105.7 | 38.1 | 129.4 | 39.5 | 156.5 | 40.8 | 187.8 | 41.9 | |||||||||
| 45 | 78.9 | 40.0 | 97.8 | 41.6 | 120.2 | 43.2 | 146.3 | 44.7 | 176.1 | 46.0 | |||||||||
| LXPL-BHF2 -110M | RC2-200B -ZP (55HP) | 2 | 35 | 183.8 | 67.2 | 226.2 | 69.8 | 275.2 | 72.2 | 332.2 | 74.6 | 397.8 | 76.4 | 200 | Φ57 | Φ108 | Φ76 | Φ76 | 2330×1700×1100 |
| 40 | 171.4 | 73.2 | 211.4 | 73.2 | 258.8 | 79.0 | 313.0 | 81.6 | 375.6 | 83.3 | |||||||||
| 45 | 157.8 | 80.0 | 195.6 | 83.2 | 240.4 | 86.4 | 292.6 | 89.4 | 352.2 | 92.0 | |||||||||
| LXPL-BHF3 -165M | 3 | 35 | 275.7 | 100.8 | 399.3 | 104.7 | 412.8 | 108.3 | 498.3 | 111.9 | 596.7 | 114.6 | 250 | Φ57 | Φ89×2 | Φ89 | Φ76 | 2300×1700×1800 | |
| 40 | 257.1 | 109.8 | 317.1 | 114.3 | 388.2 | 188.5 | 469.5 | 122.4 | 563.4 | 125.7 | |||||||||
| 45 | 236.7 | 120.2 | 293.4 | 124.8 | 360.6 | 129.6 | 438.9 | 134.1 | 528.3 | 138.0 | |||||||||
| LXPL-BHF4 -220M | M | 35 | 367.6 | 134.4 | 452.4 | 139.6 | 550.4 | 144.4 | 664.4 | 149.2 | 795.6 | 152.8 | 300 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 4400×1700×1800 | |
| 40 | 342.8 | 146.4 | 422.8 | 152.4 | 517.6 | 158.0 | 626.0 | 163.2 | 751.2 | 167.6 | |||||||||
| 45 | 315.6 | 160.0 | 391.2 | 166.4 | 480.8 | 172.8 | 585.2 | 177.8 | 704.4 | 184.0 | |||||||||
| LXPL-HF -60M | RC2-230B -Z (60HP) | 1 | 35 | 114.1 | 33.6 | 140.5 | 44.2 | 170.9 | 45.8 | 206.3 | 47.3 | 247.1 | 48.4 | 150 | Φ35 | Φ76 | Φ54 | Φ35 | 2300×900×1250 |
| 40 | 106.3 | 46.4 | 131.2 | 48.3 | 160.7 | 50.0 | 194.4 | 51.7 | 233.3 | 53.1 | |||||||||
| 45 | 97.9 | 50.7 | 121.4 | 52.8 | 149.3 | 54.7 | 181.7 | 56.6 | 218.8 | 58.2 | |||||||||
| LXPL-BHF2 -120M | RC2-230B -ZP (60HP) | 2 | 35 | 228.2 | 85.0 | 281.0 | 88.4 | 341.8 | 91.6 | 412.6 | 94.4 | 494.2 | 96.8 | 200 | Φ42 | Φ133 | Φ76 | Φ42 | 2600×1700×1900 |
| 40 | 212.6 | 92.8 | 262.4 | 96.6 | 321.4 | 100.0 | 388.8 | 103.4 | 466.6 | 106.2 | |||||||||
| 45 | 195.8 | 101.4 | 242.8 | 105.6 | 298.6 | 109.4 | 363.4 | 113.2 | 437.6 | 116.4 | |||||||||
| LXPL-BHF3 -180M | 3 | 35 | 342.3 | 127.5 | 421.5 | 132.6 | 512.7 | 134.7 | 618.9 | 141.6 | 741.3 | 145.2 | 300 | Φ54 | Φ108 ×2 | Φ76 | Φ67 | 3500×1700×1900 | |
| 40 | 318.9 | 139.2 | 393.6 | 144.9 | 482.1 | 150.0 | 583.2 | 155.1 | 699.9 | 159.3 | |||||||||
| 45 | 293.7 | 152.1 | 364.2 | 158.4 | 447.9 | 164.1 | 545.1 | 169.8 | 656.4 | 174.6 | |||||||||
| LXPL-BHF4 -240M | 4 | 35 | 456.4 | 170.0 | 562.0 | 176.8 | 683.6 | 183.2 | 825.2 | 188.8 | 988.4 | 193.6 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | |
| 40 | 425.2 | 185.6 | 524.8 | 193.2 | 642.8 | 200.0 | 777.6 | 206.8 | 933.2 | 212.4 | |||||||||
| 45 | 391.6 | 202.8 | 485.6 | 211.2 | 597.2 | 218.8 | 726.8 | 266.4 | 875.2 | 232.8 | |||||||||
| LXPL-HF -70M | RC2-260B -Z (70HP) | 1 | 35 | 123.4 | 43.8 | 151.3 | 45.6 | 184.1 | 47.2 | 222.2 | 448.7 | 266.1 | 49.9 | 150 | Φ35 | Φ76 | Φ54 | Φ35 | 2300×900×1250 |
| 40 | 114.7 | 47.9 | 141.5 | 49.8 | 173.1 | 51.6 | 209.3 | 53.3 | 251.3 | 54.7 | |||||||||
| 45 | 105.7 | 52.3 | 130.9 | 54.4 | 161.4 | 56.4 | 195.7 | 58.3 | 235.6 | 60.0 | |||||||||
| LXPL-BHF2 -140M | RC2-260B -ZP (70HP) | 2 | 35 | 246.8 | 87.6 | 302.6 | 91.2 | 368.2 | 94.4 | 444.4 | 97.4 | 532.2 | 99.8 | 200 | Φ54 | Φ133 | Φ76 | Φ54 | 2600×1700×1900 |
| 40 | 229.4 | 95.8 | 283.0 | 99.6 | 346.2 | 103.2 | 418.6 | 106.6 | 502.6 | 109.4 | |||||||||
| 45 | 211.4 | 104.6 | 261.8 | 108.8 | 322.8 | 112.8 | 391.4 | 116.6 | 471.2 | 120.0 | |||||||||
| LXPL-BHF3 -210M | 3 | 35 | 370.2 | 131.4 | 453.9 | 136.8 | 552.3 | 141.6 | 666.6 | 146.1 | 798.3 | 149.7 | 300 | Φ54 | Φ108 ×2 | Φ108 | Φ67 | 3500×1700×1900 | |
| 40 | 344.1 | 143.7 | 424.5 | 149.4 | 591.3 | 154.8 | 627.9 | 159.9 | 753.9 | 164.1 | |||||||||
| 45 | 317.1 | 156.9 | 392.7 | 163.2 | 484.2 | 169.2 | 587.1 | 174.9 | 706.8 | 180.0 | |||||||||
| LXPL-BHF4 -280M | 4 | 35 | 493.6 | 175.2 | 605.2 | 182.4 | 736.4 | 188.8 | 888.8 | 194.8 | 1064.4 | 199.6 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | |
| 40 | 458.8 | 191.6 | 566.0 | 199.2 | 692.4 | 206.4 | 837.2 | 213.2 | 1005.2 | 218.8 | |||||||||
| 45 | 422.8 | 209.2 | 523.6 | 217.6 | 645.6 | 225.6 | 782.8 | 233.2 | 942.4 | 240.0 | |||||||||
| Modelo ng Unit | Cam.Model | Com, Cuartity | Pagkondensasyon temp.(℃) | Pagsingaw Temp. (℃) | Reservoir (L) | Supply tubo (mm) | Pagsipsip tubo (mm) | Gas Outiet tubo (mm) | likido inlettubo (mm) | Dimensyon(mm) (L×W×H) | ||||||||||
| -15 | -10 | -5 | 0 | 5 | ||||||||||||||||
| Kapasidad ng Paglamig/Power lnput(kw) | ||||||||||||||||||||
| LXPL-BHF-75M | RC2-300B -Z (75HP) | 1 | 35 | 145.4 | 50.5 | 178.3 | 52.5 | 216.9 | 54.4 | 261.8 | 56.1 | 313.6 | 57.5 | 200 | Φ57 | Φ89 | Φ67 | Φ67 | 2300×900×1250 | |
| 40 | 135.3 | 55.2 | 167.3 | 57.4 | 203.9 | 59.5 | 246.6 | 61.4 | 296.1 | 63.1 | ||||||||||
| 45 | 127.4 | 60.3 | 154.4 | 62.7 | 190.1 | 65.1 | 230.6 | 67.3 | 277.6 | 69.2 | ||||||||||
| LXPL-BHF2 -150M | RC2-300B -ZP (75HP) | 2 | 35 | 290.8 | 101.0 | 356.6 | 105.0 | 433.8 | 108.8 | 523.6 | 112.2 | 627.2 | 115.0 | 250 | Φ57 | Φ133 | Φ89 | Φ76 | 2600×1700×1900 | |
| 40 | 270.6 | 101.0 | 334.6 | 114.8 | 407.8 | 119.0 | 493.2 | 122.8 | 5922 | 126.2 | ||||||||||
| 45 | 249.4 | 120.6 | 308.8 | 125.4 | 380.2 | 130.2 | 461.2 | 134.6 | 555.2 | 138.4 | ||||||||||
| LXPL-BHF3 -225M | 3 | 35 | 436.2 | 151.5 | 534.9 | 157.5 | 650.7 | 163.2 | 785.4 | 168.3 | 940.8 | 172.5 | 400 | Φ57 | Φ108 ×2 | Φ108 | Φ89 | 3500×1700×1900 | ||
| 40 | 405.9 | 165.6 | 501.9 | 172.2 | 611.7 | 178.5 | 739.8 | 184.2 | 888.3 | 189.3 | ||||||||||
| 45 | 374.1 | 180.9 | 463.2 | 188.1 | 570.3 | 195.3 | 691.8 | 201.9 | 832.8 | 207.6 | ||||||||||
| LXPL-BHF4 -300M | 4 | 35 | 581.6 | 202.0 | 731.2 | 210.0 | 867.6 | 217.6 | 1047.2 | 224.4 | 1254.4 | 230.0 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | ||
| 40 | 541.2 | 220.8 | 699.2 | 229.6 | 815.6 | 238.0 | 986.4 | 245.6 | 1184.4 | 252.4 | ||||||||||
| 45 | 498.8 | 241.2 | 617.6 | 250.8 | 760.4 | 260.4 | 922.4 | 269.2 | 1110.4 | 276.8 | ||||||||||
| LXPL-HF -80M | RC2-310B -Z (80HP) | 1 | 35 | 153.7 | 53.8 | 188.4 | 55.9 | 229.2 | 57.9 | 276.6 | 59.7 | 331.6 | 61.2 | 200 | Φ35 | Φ76 | Φ54 | Φ35 | 2600×900×1400 | |
| 40 | 142.9 | 58.7 | 176.8 | 61.1 | 215.5 | 63.3 | 260.6 | 65.3 | 312.8 | 67.1 | ||||||||||
| 45 | 131.7 | 64.1 | 163.1 | 66.7 | 200.9 | 69.2 | 243.7 | 71.6 | 293.3 | 73.6 | ||||||||||
| LXPL-BHF2 -160M | RC2-310B -ZP (80HP) | 2 | 35 | 307.4 | 107.8 | 376.8 | 111.8 | 458.4 | 115.8 | 553.2 | 119.4 | 662.6 | 122.4 | 250 | Φ57 | Φ133 | Φ76 | Φ54 | 3000×1800×2100 | |
| 40 | 285.8 | 117.4 | 353.6 | 122.2 | 431.0 | 126.6 | 521.2 | 130.6 | 625.6 | 134.2 | ||||||||||
| 45 | 263.4 | 128.2 | 326.2 | 133.4 | 401.8 | 138.4 | 487.4 | 143.2 | 586.6 | 147.2 | ||||||||||
| LXPL-BHF3 -240M | 3 | 35 | 461.1 | 161.4 | 565.2 | 167.7 | 687.6 | 173.7 | 829.8 | 179.1 | 993.9 | 183.6 | 400 | Φ54 | Φ108 ×2 | Φ108 | Φ67 | 3500×1700×1900 | ||
| 40 | 428.7 | 176.1 | 530.4 | 183.3 | 646.5 | 189.9 | 781.8 | 195.9 | 938.4 | 201.3 | ||||||||||
| 45 | 395.1 | 192.3 | 489.3 | 200.1 | 602.7 | 207.6 | 731.1 | 214.8 | 879.9 | 220.8 | ||||||||||
| LXPL-BHF4 -320M | 4 | 35 | 614.8 | 215.2 | 753.6 | 223.6 | 916.8 | 231.6 | 1106.4 | 238.8 | 1325.2 | 244.8 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4000×1700×1900 | ||
| 40 | 571.6 | 234.8 | 707.2 | 244.4 | 862.0 | 253.2 | 1042.4 | 261.2 | 1251.2 | 268.4 | ||||||||||
| 45 | 526.8 | 256.4 | 376.8 | 266.8 | 803.6 | 276.8 | 974.8 | 286.4 | 1173.2 | 299.4 | ||||||||||
| LXPL-HF -90M | RC2-340B -Z (90HP) | 1 | 35 | 171.1 | 58.0 | 209.8 | 60.3 | 255.2 | 62.5 | 308.0 | 64.4 | 368.9 | 66.1 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 2600×850×1400 | |
| 40 | 159.3 | 63.4 | 196.8 | 65.9 | 239.9 | 68.3 | 290.1 | 70.5 | 348.3 | 72.4 | ||||||||||
| 45 | 146.9 | 69.2 | 181.8 | 72.0 | 223.7 | 74.7 | 271.3 | 77.2 | 326.6 | 79.5 | ||||||||||
| LXPL-BHF2 -180M | RC2-340B -ZP (90HP) | 2 | 35 | 342.2 | 116.0 | 419.6 | 120.6 | 510.4 | 125.0 | 616.0 | 128.8 | 737.8 | 132.2 | 300 | Φ54 | Φ133 | Φ76 | Φ54 | 3000×1800×2100 | |
| 40 | 318.9 | 126.8 | 393.6 | 131.8 | 479.8 | 136.6 | 580.2 | 141.0 | 696.6 | 144.8 | ||||||||||
| 45 | 293.8 | 138.4 | 363.8 | 144.0 | 447.4 | 149.4 | 542.6 | 154.4 | 653.2 | 159.0 | ||||||||||
| LXPL-BHF3 -270M | 3 | 35 | 513.3 | 174.0 | 629.4 | 180.9 | 765.6 | 187.5 | 924.0 | 193.2 | 1106.7 | 198.3 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 3800×1800×2100 | ||
| 40 | 477.9 | 190.2 | 590.4 | 197.7 | 719.7 | 204.9 | 870.3 | 211.5 | 1044.9 | 217.2 | ||||||||||
| 45 | 440.7 | 207.6 | 545.4 | 216.0 | 671.1 | 224.1 | 813.9 | 231.6 | 979.8 | 238.5 | ||||||||||
| LXPL-BHF4 -360M | 4 | 35 | 684.4 | 232.0 | 839.2 | 241.2 | 1020.8 | 250.0 | 1232.0 | 2576 | 1475.6 | 264.4 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 4600×1800×2100 | ||
| 40 | 637.2 | 253.6 | 787.2 | 263.6 | 959.6 | 273.2 | 1160.4 | 282.0 | 1393.2 | 289.6 | ||||||||||
| 45 | 587.6 | 276.8 | 727.2 | 288.0 | 894.8 | 298.8 | 1085.2 | 308.8 | 1306.4 | 318.0 | ||||||||||
| Modelo ng Unit | Com.Model | Com, Curtity | Pagkondensasyon temp. (℃) | Pagsingaw Temp. (℃) | Reservoir (L) | Supply tubo (mm) | Pagsipsip tubo (mm) | Gas Outiet tubo (mm) | likido inlettubo (mm) | Dimensyon(mm) (LxW×H) | ||||||||||
| -15 | -10 | -5 | 0 | 5 | ||||||||||||||||
| Collng Capacity/Power lnput(kw) | ||||||||||||||||||||
| LXPL-BHF -100M | RC2-370B -Z (100HP) | 1 | 35 | 184.3 | 62.7 | 226.0 | 65.2 | 274.8 | 67.5 | 331.7 | 69.6 | 397.3 | 71.3 | 100 | Φ42 | Φ108 | Φ67 | Φ57 | 2600×850×1400 | |
| 40 | 171.5 | 68.4 | 212.0 | 71.5 | 285.4 | 73.8 | 312.5 | 76.2 | 375.1 | 78.3 | ||||||||||
| 45 | 158.1 | 74.8 | 195.8 | 77.8 | 240.9 | 80.7 | 292.2 | 83.4 | 351.7 | 85.8 | ||||||||||
| LXPL-BHF2 -200M | RC2-370B -ZP (100HP) | 2 | 35 | 368.6 | 125.4 | 452.0 | 130.4 | 549.6 | 135.0 | 663.4 | 139.2 | 794.6 | 142.8 | 300 | Φ54 | Φ159 | Φ108 | Φ67 | 3500×1900×2100 | |
| 40 | 343.0 | 136.8 | 424.0 | 142.4 | 516.8 | 147.6 | 625.0 | 152.4 | 750.2 | 156.4 | ||||||||||
| 45 | 316.2 | 149.6 | 391.6 | 155.6 | 481.8 | 161.4 | 584.4 | 166.8 | 703.4 | 171.8 | ||||||||||
| LXPL-BHF3 -300M | 3 | 35 | 552.9 | 188.1 | 678.0 | 195.6 | 824.4 | 202.5 | 995.1 | 208.8 | 1191.9 | 214.2 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1900×2100 | ||
| 40 | 514.5 | 205.2 | 636.0 | 213.6 | 775.2 | 221.4 | 937.5 | 228.6 | 1125.3 | 234.6 | ||||||||||
| 45 | 474.3 | 224.4 | 587.4 | 233.4 | 722.7 | 242.1 | 876.6 | 205.2 | 1055.1 | 257.7 | ||||||||||
| LXPL-BHF4 -400M | 4 | 35 | 737.2 | 250.8 | 904.0 | 260.8 | 1099.2 | 270.0 | 1326.8 | 278.4 | 1589.2 | 285.6 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 5300×1900×2100 | ||
| 40 | 686.0 | 273.6 | 848.0 | 284.8 | 1033.6 | 295.2 | 1250.0 | 304.8 | 1500.4 | 312.8 | ||||||||||
| 45 | 632.4 | 299.2 | 783.2 | 313.2 | 963.6 | 322.8 | 1168.8 | 333.6 | 1406.8 | 343.6 | ||||||||||
| LXPL-HF -110M | RC2-410B -Z (110HP) | 1 | 35 | 200.4 | 69.3 | 245.9 | 72.1 | 298.8 | 67.5 | 360.6 | 77.0 | 432.0 | 78.9 | 250 | Φ42 | Φ108 | Φ67 | Φ54 | 2750×850×1450 | |
| 40 | 186.4 | 75.7 | 230.5 | 78.7 | 280.9 | 81.6 | 339.8 | 84.3 | 407.9 | 86.5 | ||||||||||
| 45 | 171.8 | 82.7 | 212.8 | 86.0 | 261.9 | 89.3 | 317.7 | 92.3 | 352.8 | 95.0 | ||||||||||
| LXPL-BHF2 -220M | RC2-410B -ZP (110HP) | 2 | 35 | 400.8 | 138.6 | 491.4 | 144.2 | 597.6 | 135.0 | 721.2 | 154.0 | 864.0 | 157.8 | 300 | Φ57 | Φ159 | Φ108 | Φ76 | 3500×1900×2150 | |
| 40 | 372.8 | 151.4 | 461.0 | 157.4 | 561.8 | 163.2 | 679.6 | 168.6 | 815.8 | 137.0 | ||||||||||
| 45 | 343.6 | 165.4 | 425.6 | 172.0 | 523.8 | 178.6 | 635.4 | 184.6 | 764.8 | 190.0 | ||||||||||
| LXPL-BHF3 -330M | 3 | 35 | 601.2 | 207.9 | 737.1 | 216.3 | 896.4 | 202.5 | 1081.8 | 231.0 | 1296.0 | 236.7 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1000×2150 | ||
| 40 | 559.2 | 227.1 | 691.5 | 236.1 | 842.7 | 244.8 | 1019.4 | 252.9 | 1223.7 | 259.5 | ||||||||||
| 45 | 515.4 | 248.1 | 638.4 | 258.0 | 785.7 | 267.9 | 953.1 | 276.9 | 1147.2 | 285.0 | ||||||||||
| LXPL-BHF4 -440M | 4 | 35 | 801.6 | 277.2 | 982.8 | 288.4 | 1195.2 | 270.0 | 1442.4 | 308.0 | 1728.0 | 315.6 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 5300×1900×2150 | ||
| 40 | 745.6 | 302.8 | 922.0 | 314.8 | 1123.6 | 326.4 | 1359.2 | 337.2 | 1631.6 | 346.0 | ||||||||||
| 45 | 687.2 | 330.8 | 851.2 | 344.0 | 1047.6 | 357.2 | 1270.8 | 369.2 | 1529.6 | 380.0 | ||||||||||
| LXPL-HF -125M | RC2-470B -Z (125HP) | 1 | 35 | 238.6 | 80.1 | 292.5 | 83.3 | 355.8 | 86.3 | 429.4 | 88.9 | 514.3 | 91.2 | 250 | Φ42 | Φ108 | Φ67 | Φ54 | 2750×870×1450 | |
| 40 | 222.2 | 87.5 | 274.4 | 91.0 | 334.5 | 94.3 | 404.5 | 97.3 | 485.6 | 100.0 | ||||||||||
| 45 | 204.8 | 95.5 | 253.6 | 994 | 311.9 | 103.1 | 378.3 | 106.6 | 455.3 | 109.7 | ||||||||||
| LXPL-BHF2 -250M | RC2-470B -ZP (125HP) | 2 | 35 | 477.2 | 160.2 | 585.0 | 166.6 | 711.6 | 172.6 | 858.8 | 177.8 | 1028.6 | 182.4 | 400 | Φ57 | Φ159 | Φ108 | Φ67 | 3500×1900×2550 | |
| 40 | 444.4 | 1750 | 548.8 | 182.0 | 699.0 | 188.6 | 809.0 | 194.5 | 971.2 | 200.0 | ||||||||||
| 45 | 409.8 | 191.0 | 507.2 | 198.8 | 623.8 | 206.2 | 756.6 | 213.2 | 910.6 | 219.4 | ||||||||||
| LXPL-BHF3 -375M | 3 | 35 | 715.8 | 240.3 | 877.5 | 249.9 | 1067.4 | 258.9 | 1288.2 | 266.7 | 1542.9 | 273.6 | 600 | Φ57 | Φ133 ×2 | Φ133 | Φ89 | 4500×1900×2500 | ||
| 40 | 666.6 | 262.5 | 838.2 | 273.0 | 1003.5 | 282.9 | 1213.5 | 291.9 | 1456.8 | 300.0 | ||||||||||
| 45 | 614.4 | 286.5 | 760.8 | 298.2 | 935.7 | 309.3 | 1134.9 | 319.8 | 1365.9 | 329.1 | ||||||||||
| LXPL-BHF4 -500M | 4 | 35 | 954.4 | 320.4 | 1170.0 | 333.2 | 1423.2 | 3452 | 1717.6 | 355.6 | 2057.2 | 364.8 | 800 | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5400×1900×2500 | ||
| 40 | 888.8 | 350.01 | 1097.6 | 364.0 | 1338.0 | 377.2 | 1618.0 | 389.2 | 1942.4 | 438.8 | ||||||||||
| 45 | 819.2 | 382.0 | 1014.4 | 397.6 | 1247.6 | 412.4 | 1513.2 | 426.4 | 1821.2 | 438.8 | ||||||||||
| Modelo ng Unit | Com.Model | Cam. Cuartity | Pagkondensasyon temp. (℃) | Pagsingaw Temp. (℃) | Reservoir (L) | Supply tubo (mm) | Pagsipsip tubo (mm) | Gas Outiet tubo (mm) | likido inlettubo (mm) | Dimensyon(mm) (L×W×H) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Coling CapacityPower lnput (kw) | |||||||||||||||||||
| LXPL-BHF -130M | RC2-510B -Z (130HP) | 1 | 35 | 254.3 | 85.9 | 311.9 | 89.3 | 379.3 | 92.5 | 457.8 | 95.4 | 548.3 | 97.8 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 236.8 | 93.8 | 292.6 | 97.5 | 356.6 | 101.1 | 431.3 | 104.4 | 517.7 | 107.2 | |||||||||
| 45 | 218.3 | 102.4 | 270.3 | 106.6 | 332.5 | 110.6 | 403.3 | 114.3 | 485.5 | 117.6 | |||||||||
| LXPL-BHF2 -260M | RC2-510B -ZP (130HP) | 2 | 35 | 508.6 | 171.8 | 623.8 | 178.6 | 758.6 | 185.0 | 915.6 | 190.8 | 1096.6 | 195.6 | 400 | Φ57 | Φ159 | Φ133 | Φ89 | 3250×2100×1750 |
| 40 | 473.6 | 187.6 | 585.2 | 195.0 | 713.2 | 202.2 | 862.6 | 208.8 | 1035.4 | 214.4 | |||||||||
| 45 | 436.6 | 204.8 | 540.6 | 213.2 | 665.0 | 221.2 | 806.6 | 228.6 | 971.0 | 235.2 | |||||||||
| LXPL-BHF3 -390M | 3 | 35 | 762.9 | 257.7 | 935.7 | 267.9 | 1137.9 | 277.5 | 1373.4 | 286.2 | 1644.9 | 293.4 | 600 | Φ76 | Φ133 ×2 | Φ159 | Φ89 | 4350×2100×1800 | |
| 40 | 710.4 | 281.4 | 877.8 | 292.5 | 1069.8 | 303.3 | 1293.9 | 313.2 | 1553.1 | 321.6 | |||||||||
| 45 | 654.9 | 307.2 | 810.9 | 319.8 | 997.5 | 331.8 | 1209.9 | 342.9 | 1456.5 | 352.8 | |||||||||
| LXPL-BHF4 -520M | 4 | 35 | 1017.2 | 343.6 | 1247.6 | 357.2 | 1517.2 | 370.0 | 1831.2 | 381.6 | 2193.2 | 391.2 | 800 (Sa labas) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5400×2100×2050 | |
| 40 | 947.2 | 375.2 | 1170.4 | 390.0 | 1426.4 | 404.4 | 1725.2 | 417.66 | 2070.8 | 428.8 | |||||||||
| 45 | 873.2 | 409.6 | 1081.2 | 426.4 | 1330.0 | 442.4 | 1613.2 | 457.2 | 1942.0 | 470.4 | |||||||||
| LXPL-HF -140M | RC2-550B -Z (140HP) | 1 | 35 | 271.3 | 94.4 | 322.6 | 98.2 | 404.6 | 101.7 | 488.3 | 104.9 | 584.8 | 107.5 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 252.3 | 103.1 | 312.1 | 107.3 | 380.3 | 111.2 | 460.0 | 114.8 | 552.2 | 117.9 | |||||||||
| 45 | 232.5 | 112.7 | 288.0 | 117.2 | 354.6 | 121.6 | 430.1 | 125.7 | 517.8 | 129.4 | |||||||||
| LXPL-BHF2 -280M | RC2-550B -ZP (140HP) | 2 | 35 | 542.6 | 188.8 | 665.2 | 196.4 | 809.2 | 203.4 | 976.6 | 209.8 | 1169.6 | 215.0 | 400 | Φ57 | Φ159 | Φ133 | Φ89 | 3400×2150×1750 |
| 40 | 504.6 | 206.2 | 624.2 | 214.6 | 760.6 | 222.4 | 920.0 | 229.6 | 1104.4 | 235.8 | |||||||||
| 45 | 465.0 | 225.4 | 576.0 | 234.4 | 709.2 | 243.2 | 860.2 | 251.4 | 1035.6 | 258.8 | |||||||||
| LXPL-BHF3 -420M | 3 | 35 | 813.9 | 2832 | 997.8 | 294.6 | 1213.8 | 305.1 | 1464.9 | 314.7 | 1754.4 | 322.5 | 600 | Φ76 | Φ133 ×2 | Φ159 | Φ89 | 4550×2150×2050 | |
| 40 | 765.9 | 309.3 | 936.3 | 321.9 | 1140.9 | 333.6 | 1380.0 | 344.4 | 1656.6 | 353.7 | |||||||||
| 45 | 697.5 | 338.1 | 864.0 | 351.6 | 1063.8 | 364.8 | 1290.3 | 377.1 | 1553.4 | 388.2 | |||||||||
| LXPL-BHF4 -560M | 4 | 35 | 1085.2 | 377.6 | 1330.4 | 392.8 | 1618.4 | 406.8 | 1953.2 | 419.6 | 2339.2 | 430.0 | 800 (Sa labas) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5600×2150×2050 | |
| 40 | 1009.2 | 412.4 | 1248.4 | 4292 | 1521.2 | 444.8 | 1840.0 | 459.2 | 2208.8 | 471.6 | |||||||||
| 45 | 930.0 | 450.8 | 1152.0 | 466.8 | 1418.4 | 486.4 | 1720.4 | 502.8 | 2071.2 | 517.6 | |||||||||
| LXPL-HF -150M | RC2-580B -Z (150HP | 1 | 35 | 299.9 | 101.6 | 367.7 | 105.7 | 447.2 | 109.5 | 539.8 | 112.9 | 646.5 | 115.8 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 279.2 | 111.0 | 345.0 | 115.5 | 420.4 | 119.7 | 508.5 | 123.6 | 610.4 | 126.9 | |||||||||
| 45 | 257.4 | 121.3 | 318.6 | 126.2 | 392.0 | 130.9 | 475.5 | 135.3 | 572.4 | 139.3 | |||||||||
| LXPL-BHF2 -300M | RC2-580B -ZP (150HP) | 2 | 35 | 599.8 | 203.2 | 735.4 | 211.4 | 894.4 | 219.0 | 1079.6 | 225.8 | 1293.0 | 231.6 | 500 | Φ57 | Φ159 | Φ133 | Φ89 | 3500×2150×1750 |
| 40 | 558.4 | 222.0 | 690.0 | 231.0 | 840.8 | 239.4 | 1017.0 | 247.2 | 1220.8 | 253.8 | |||||||||
| 45 | 514.8 | 242.6 | 637.2 | 252.4 | 784.0 | 261.8 | 951.0 | 270.5 | 1144.8 | 278.5 | |||||||||
| LXPL-BHF3 -450M | 3 | 35 | 899.7 | 304.8 | 1103.1 | 317.1 | 1341.6 | 328.5 | 1619.4 | 338.7 | 1939.5 | 347.4 | 800 (Sa labas) | Φ76 | Φ133 ×2 | Φ133 | Φ108 | 4650×2150×2050 | |
| 40 | 837.6 | 333.0 | 1035.0 | 346.51 | 1261.2 | 359.1 | 1525.5 | 370.8 | 1831.2 | 380.7 | |||||||||
| 45 | 772.2 | 363.9 | 955.8 | 378.6 | 1176.0 | 392.7 | 1426.5 | 405.9 | 1717.2 | 417.9 | |||||||||
| LXPL-BHF4 -600M | 4 | 35 | 1199.6 | 406.4 | 1470.8 | 422.8 | 1788.8 | 438.0 | 2159.2 | 451.6 | 2586.0 | 463.2 | 800 (Sa labas) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5800×2150×2350 | |
| 40 | 1116.8 | 444.0 | 1380.0 | 462.0 | 1681.6 | 478.8 | 2034.0 | 494.4 | 2441.6 | 507.6 | |||||||||
| 45 | 1029.6 | 485.2 | 1274.4 | 504.8 | 1568.0 | 5236 | 1902.0 | 541.2 | 2289.6 | 557.2 | |||||||||
Pagpapakita ng Detalye
Makipag-ugnayan sa Amin
TUNGKOL SA AMIN
Zhejiang Lanxi Refrigeration Equipment Co., Ltd.
Bilang Tsina Hanbell Medium to High Temperature Unit Mga Tagatustos at Hanbell Medium to High Temperature Unit Pabrika,
Zhejiang Lanxi Refrigeration Equipment Co., Ltd. dalubhasa sa mahusay, luntian, at napapanatiling mga solusyon sa pagpapalamig. Sa paggamit ng mga de-kalidad na produkto at makabagong teknolohiya, pinaglilingkuran namin ang mga sektor ng pagkain, parmasyutiko, kemikal, at cold chain logistics, na lumilikha ng mga sistemang matipid sa enerhiya at pangkalikasan para sa aming mga kostumer at nagtataguyod ng kapwa kapaki-pakinabang na pag-unlad para sa industriya at kapaligiran.
Sertipiko ng Karangalan
Balita
-
Pumunta sa isang malamig na storage room at pakiramdaman ang hangin malapit sa pinto. Kung ang isang sulok ay mas mainit kaysa sa isa pa, o ang temperatura ay umaanod paitaas tuwing hapon, ang pang-industriyang air cooler na naka-moun...
MAGBASA PA -
Kapag sinusuri ng planta sa pagpoproseso ng pagkain sa isang rehiyong kulang sa tubig ang mga opsyon nito sa pagpapalamig, kadalasang nagpapasya ang pagpili ng condenser kung maaaprubahan ang proyekto. Ang mga condenser na pinalamig n...
MAGBASA PA -
Habang naghahanap ng isang tagagawa ng evaporator at condenser , Ang Lanxi Refrigeration ay tiyak na nagkakahalaga ng iyong pansin. May mga natatanging bentahe sa disenyo at produksyon ng condenser, ang Lanxi Refrigeration ay nagh...
MAGBASA PA
MAKIPAG-UGNAYAN SA AMIN
MGA MABILIS NA LINK
MGA PRODUKTO
IMPORMASYON SA KONTAK
- Email: [email protected]
- Telepono: +86-15258555916
- Idagdag: 301 Punan Avenue, Pukou Street, Shengzhou City, Shaoxing City, Zhejiang Province.China
Copyright © Zhejiang Lanxi Refrigeration Equipment Co., Ltd. Lahat ng Karapatan ay Nakalaan.
浙ICP备2022034605号-1
Pakyawan Hanbell Medium to High Temperature Unit Pabrika
